GLF1521

5 A Load Switch with Programmable Slew Rate Control

home Product Load Switch IC GLF1521
Product Features

  • Input Voltage Range

    VIN: 0.6 V to 3.6 V

  • Supply voltage range

    VBIAS: 2.5 V to 3.6 V

  • Ultra-Low On-Resistance

    RON: 22 mΩ

  • 5 A Maximum Continuous Output Current

  • Low Quiescent Current

    IQ_BIAS: 15 µA at VBIAS = 3.3 V

  • Reverse Current Blocking during off state

  • Built-In Thermal Shutdown

  • Programmable VOUT Rise Time

  • Internal EN Pull-Down Resistor

  • Output Discharge Switch

GLF1521
Product manual
Sample application
Product Description

The GLF1521 is an integrated load switch with a programmable slew rate control to provide variable output voltage rising times by an external capacitor to minimize inrush current.


The GLF1521 operates in an input range from 0.6 V to 3.6 V and supports 5 A maximum continuous output current. The GLF1521 features a low RON, quiescent current (IQ) and shutdown current (ISD), which support implementation of better system efficiency.


The GLF1521 is available in 2 mm x 2 mm DFN package with a thermal bad on the bottom for high power dissipation.
